i.Characteristics And Advantages

Light Weight And High Strength:

The main structure of light steel villa is composed of high-strength cold-formed thin-walled steel, which has high strength and toughness, making the whole building structure both light and strong.

Fast Construction:

As the components of light steel villa can be prefabricated in the factory and only need to be assembled on site, it greatly shortens the construction cycle and improves the construction efficiency.

Usually, the main frame can be completed within 15-20 days.

Energy-saving And Environmental Protection:

Light steel villa produces less construction waste during the construction process, and the materials can be recycled, reducing the impact on the environment.

Meanwhile, its walls and roofs are usually filled with thermal insulation materials, which can effectively isolate the temperature exchange between indoor and outdoor and improve the living comfort.

Superior Anti-seismic And Wind-resistant Performance:

The flexible connection structure of light steel villa makes it have better anti-seismic and wind-resistant performance in the face of natural disasters such as earthquakes and storms.

In principle, the light steel villa can reach the ability of grade 9 earthquake resistance and grade 12 wind resistance.

Flexible Space Layout:

The walls of light steel villa are thinner, which can provide more space for use. At the same time, the internal space layout can be flexibly adjusted according to the needs of the occupants.

Artistic Appreciation:

The design of light steel villa is modern and fashionable, which can meet the personalised needs of the occupants. Its appearance has various modelling and the internal design can be flexible.

Strong Durability:

The main structure of light steel villa is corrosion-resistant, with long service life and low maintenance cost.

Number Of Floors:

Due to the light weight of light steel, its bearing capacity is limited, and it is generally suitable to withstand low-rise buildings (up to 6 floors).

To build a high-rise house with more than 6 floors, a combination of light and heavy steel is required.

ii.Construction Process

Foundation Treatment:

The foundation treatment of light steel villa is the same as that of traditional brick structure foundation, including the steps of choosing location,

clearing the ground, placing the line of foundation pit, digging the trench, checking the trench, placing the line, pouring the bedding layer and maintaining it,

and locating and placing the line.

Prefabrication And Assembly Of Main Structure:

The main structure is prefabricated and assembled into modules first, and then all modules can be assembled manually.

This includes steps such as indoor floor concrete pouring, wall assembly, floor beam splicing and roof building.

The connection assembly method mainly adopts bolting to ensure that the house is firmly connected to the foundation.

Decoration Of Internal And External Walls:

After filling the external side of the external wall pair with glass fibre cotton, structural boards, moisture-resistant breathable paper, extruded plastic boards, etc.

Are nailed as thermal insulation materials, and then steel wire mesh and stucco layers are nailed as decoration.

The inner side of the outer wall and the inner wall are directly filled with glass fibre wool in the light steel structure nailed to the gypsum board.

The floor is filled with glass fibre cotton, and then nailed in the order of structural panels, concrete pads, floor decoration layer, and so on.

Doors And Windows Installation And Interior Decoration:

After the construction is completed, doors and windows are installed and interior decoration is carried out.

The interior decoration of light steel villa can be realised in various styles according to personal preference.

iii.Application Fields

Light steel villa is suitable for a variety of fields, including private houses, tourist resorts, post-disaster reconstruction and commercial buildings.

It can provide a comfortable and environmentally friendly living environment for people pursuing high quality of life;

Fast construction of holiday villas to meet the development needs of tourism;

Fast reconstruction of housing after natural disasters to provide temporary or permanent living solutions;

And flexible spatial layout and fast construction cycle for commercial buildings such as office buildings and hotels.

Maybe You Ask

1.How Long Will The Light Steel Villa Be Used And Its Safety?

Service Life:

The load-bearing structure of light steel villa is designed to have a service life of up to 90 years,

Which is three times as long as that of ordinary houses, and there is no problem in normal use for seventy years.

Safety:

Light steel villa meets the building requirements in earthquake and hurricane resistance, very strong, can resist 9 level earthquake, 12-13 level typhoon.

At the same time, light steel components can direct the current generated by lightning strikes into the ground to protect the occupants from injury.

2. What Materials Are Used In Light Steel Villas?

Construction:

The light steel villa is treated with hot-dip galvanised or almost pure zinc metal coating for corrosion prevention and will not rust.

The whole house is grounded and the circuit is safe.

Materials:

Calcium silicate version is used for the inner wall of the light steel villa, and gypsum board is used for the ceiling.

Calcium silicate board is high strength, light weight, and has good workability and non-combustibility.

3. How About The Lightning Protection And Moisture-proof Effect Of Light Steel Villa?

Lightning Protection:

the galvanised material of light steel villa is a complete lightning protection system when it is closely connected with the ground,

And there is no need to do special lightning protection measures.

Moisture-proof:

light steel villa adopts closed moisture-proof system, which can effectively control the corrosion of steel and ensure the structure life is greater than the service life of the residence.

4. Are Light Steel Villas Really Fireproof?

Light steel villas do have fire resistance.The main structure of light steel villa adopts light steel keel, light steel itself is non-combustible material, which improves the fire safety of the building to a certain extent.

Light steel villa will use all kinds of fireproof materials to assist in the construction process. For example, parts such as walls and roofs will be filled with insulation materials with good fireproof performance, such as glass fibre cotton, which are basically non-combustible.

At the same time, the walls, roofs, floors and other parts of the light steel villa also use fire-retardant materials such as osone boards, calcium silicate boards and other fire-retardant materials. These materials will not burn when encountering an open flame, but will only blacken and carbonise, thus effectively preventing the spread of fire.

However, it is also important to note that despite the better fire resistance of light steel villas, the performance of the steel will be affected under high temperature conditions. When the temperature exceeds a certain level, the strength and hardness of the steel will be significantly reduced and even deformed.

Therefore, in order to improve the fireproof performance of light steel villa, additional measures such as fireproof coating and fireproof wall body are often required.

5.Is The Quality Of Light Steel Villa Reliable?

The quality of light steel villa is reliable under the premise of reasonable design, standardised construction and selection of high quality materials.

Light steel villa adopts light steel keel as the main structural support material, and this structural system has the characteristics of light weight, high strength, fast construction and flexible design.

The construction process of light steel villa is very innovative, light steel structure in the factory based on accurate design is cut into specific sizes, complete precision processing and manufacturing, transported to the construction site for assembly, abandoning the traditional building site masonry brick wall, long time mixing cement and other complicated processes, which greatly saves the construction time and reduces the construction cost.

However, The Quality Of Light Steel Villas Is Also Affected By Some Factors.

For example, the quality of light steel keel varies in the market, and some unscrupulous merchants use inferior materials to substitute good ones, which can affect the structural safety of the houses.

Therefore, when buying light steel keel, you need to check the product inspection report and choose materials with high hot-dip galvanising content and thickness that meet the standard.

In addition, the professional level and construction experience of the construction team also has an important impact on the quality of light steel villa.

Unqualified construction teams or construction personnel lacking professional knowledge may lead to various errors in the construction process, thus affecting the quality of the house.

Therefore, be sure to choose a qualified construction team with a good reputation.
